PALO ALTO PAN-PA-440 8-PORT 1Gb RJ-45 Ethernet Firewall Security Appliance

General Information

MPN	PAN-PA-440
Brand	Palo Alto Networks
Model	PA-440
Product Type	Firewall Appliance

Performance and Capacities Specifications

Firewall throughput (HTTP/appmix)	3.0 / 2.4 Gbps
Threat Prevention throughput (HTTP/appmix)	0.9 / 1.0 Gbps
IPsec VPN throughput	1.6 Gbps
Max sessions	200,000
New sessions per second	39,000

Networking Features

Interface Modes	L2, L3, tap, virtual wire (transparent mode)
Routing	OSPFv2/v3 with graceful restart, BGP with graceful restart, RIP, static routing Policy-based forwarding Point-to-point protocol over Ethernet (PPPoE) Multicast: PIM-SM, PIM-SSM, IGMP v1, v2, and v3
SD-WAN	Path quality measurement (jitter, packet loss, latency) Initial path selection (PBF) Dynamic path change
IPv6	L2, L3, tap, virtual wire (transparent mode) Features: App-ID, User-ID, Content-ID, WildFire, and SSL Decryption SLAAC
IPsec VPN	Key exchange: manual key, IKEv1 and IKEv2 (pre-shared key, certificate-based authentication) Encryption: 3DES, AES (128-bit, 192-bit, 256-bit) Authentication: MD5, SHA-1, SHA-256, SHA-384, SHA-512

Hardware Specifications

I/O	10/100/1000 (8) RJ45
Management I/O	10/100/1000 out-of-band management port (1), RJ45 console port (1), USB port (1), Micro USB console port (1)
Storage Capacity	128 GB eMMC
Power supply (Avg/max power consumption)	29/34 W
Max BTU/HR	117
Input Voltage (Input Frequency)	100–240 VAC (50–60 Hz)
Max Current Consumption	2.9 A @ 12 VDC
Max Inrush Current	3.3 A
Dimensions	1.74” H x 8.83” D x 8.07” W
Weight	2.2 kg
Safety	cTUVus, CB
EMI	FCC Class B, CE Class B, VCCI Class B

Environment

Operating temperature	32° to 104° F / 0° to 40° C
Non-operating temperature	-4° to 158° F / -20° to 70° C Passive cooling
