IP500V2 AVAYA IPO IP500 V2 CONTROL UNIT NO SYSTEM SD 700476005

Brand: AVAYA | Part Number: IP500V2
  • Out-of-Stock
225.99 zł
Tax excluded
local_shipping In delivery : 3 - 5 days
Condition: Refurbished help_outline
Warranty:  1 year


Security Policy



Delivery Policies



Return Policies

Quantity
Out-of-Stock

Trustpilot
  • We ship all over the world
  • All items shipped from our warehouse
  • Easy and fast ordering 24/7
  • Express international shipping in 24 hours
  • Express delivery of even 1-2 working days
If you order now, we'll ship it in:
hours
minutes
seconds
Description
IP500V2
AVAYA IPO IP500 V2 CONTROL UNIT NO SYSTEM SD 700476005

The IP500 V2 control unit is a stackable unit. The IP500 V2 control unit has 4 slots for the insertion of base cards. The slots are numbered 1 to 4 from left to right. They can be used in any order. However, if the capacity for a particular type of card is exceeded, the card in the rightmost slot is disabled. The unit must not be used with uncovered slots.

Inside:
2 x AVAYA IP OFFICE 500 COMBINATION CARD WITH 2 BRI TRUNK INTERFACES 6 PORT DIGITAL STATION 2 PHONE PORTS FOR IP500 V2 - 700476021

Maximum Extensions
Up to 384 extensions
Conference Parties
128 as standard but maximum 64 in any individual conference. Silence suppression is applied to conferences with more than 10 parties.
Trunks Cards
4 x IP500 trunk daughter cards. Some base cards can also be fitted with trunk cards.
Voice Compression Channels
Up to 148 channels using IP500 VCM and IP500 Combination cards.
Voicemail Channels
Maximum 40 usable for Voicemail Pro/TAPI WAV connection sessions subject to available licenses. For Embedded Voicemail, up to 6 (2 by default, additional channels require licenses)
Locales
Supported in all IP Office locales.
Mounting
Free-standing, rack mounted (requires IPO IP500 RACK MNTG KIT) or wall mounted (requires IPO IP500 WALL MNTG KIT).
Dimensions
Width: 445mm/17.5". Depth: 365mm/14.4". Height: 73mm/2.9"/2U. Clearance: 90mm minimum all sides, 220m at front.
Memory
Maximum configuration file size: 2048KB.
PSUInternal power supply unit.

Warranty
The product is covered by a one-year warranty. If you need an extension or warranty care, please contact us.
