Mellanox MSB7790-ES2F 36x QSFP28 100Gb - Infiniband Switch
Brand:
MELLANOX
|
Part Number: MSB7790-ES2F
Description
Mellanox MSB7790-ES2F 36x QSFP28 100Gb - Infiniband Switch
Built with Mellanox’s latest Switch-IB™ InfiniBand switch device, EDR uses efficient 64/66 encoding while increasing the per lane signaling rate to 25Gb/s. The SB7790 provides up to thirtysix 100Gb/s full bi-directional bandwidth per port.
These stand-alone switches are an ideal choice for top-of-rack leaf connectivity or for building small to extremely large sized clusters.
The SB7790 enables efficient computing with features such as static routing, adaptive routing, and congestion control. These features ensure the maximum effective fabric bandwidth by eliminating congestion hot spots.
This is a perfect solution for :
- High-Performance Computing (HPC) Clusters: This is the primary use case. The MSB7790-ES2F is designed to connect a large number of compute nodes in a cluster, providing the massive bandwidth (100 Gbps per port) and incredibly low latency (90ns) needed for parallel processing and scientific research.
- Artificial Intelligence (AI) and Machine Learning (ML) Infrastructure: AI and ML workloads, especially those involving deep learning, require moving vast datasets between GPUs and storage at very high speeds. The MSB7790-ES2F's InfiniBand technology is specifically engineered for this type of data-intensive, distributed computing.
- High-Frequency Trading (HFT): In the financial sector, where every nanosecond counts, the ultra-low latency of this switch is a critical advantage. It can be used to connect trading servers and market data feeds, ensuring the fastest possible execution of trades.
- Data-Intensive Data Centers: For data centers that handle large-scale analytics, big data processing, or cloud services, this switch can serve as a non-blocking fabric to eliminate congestion and ensure that high-bandwidth applications get the performance they need.
- Connecting High-Performance Storage Arrays: The switch is ideal for creating a high-speed backbone for storage. It can connect high-performance, parallel file systems or storage appliances to compute clusters, ensuring fast data ingestion and retrieval for I/O-heavy tasks.
Future proof Hardware
Power Up Your Connectivity
Boost your network's speed and reliability with brand-new devices. It's not just an upgrade, it's a solid foundation for your infrastructure needs, now and in the future. Enjoy faster connections for all your devices today, and rest easy knowing your network is ready for whatever comes next.
RELIABLE DELIVERY
Packaged Securely
Your product will arrive packaged carefully, according to internal standards of item protection. The item is handled professionally, you can be sure that your order will arrive in perfect condition.
ALWAYS ON TIME
With Our Own Logistics
Thanks to our own fleet of vehicles, we are able to ensure fast and reliable delivery of very large goods, such as complete server systems and data centers. We offer individual service and full control over the transport of your goods. Trust us to take care of your transport needs and deliver your products on time within Europe
SPECIFICATION
| Manufacturer | Mellanox |
| Product Line | SB7700 Series |
| Model | MSB7790-ES2F |
| Ports | 36 x 100Gb QSFP28 |
| Management | Fully Managed |
| Stackable | Yes |
| Internal Ports | Not Applicable |
| Form Factor | 1U Rack Mountable |
| Layer | 2 |
| POE Standard | No |
| POE Power | N/A |
| Switching Capacity | 7.2 Tbps |
| Mounting | NO |
| PSU | 2x 460W (PN: MTEF-PSF-AC-A) |
| Cooling | 4x Front-to-Rear, Redundant Fans (PN: MTEF-FANF-A) |
| Condition | A used item that has been kept in perfect conditions in a large data center. Looks like new, with no signs of use. Comes from a legitimate source. |
| Warranty | 1 Year |
DETAILED SPECIFICATION
| Feature / Characteristic | Specification |
|---|---|
| InfiniBand Ports | 36 (QSFP28 ports) |
| InfiniBand Speed (per port) | 100 Gb/s (EDR - Enhanced Data Rate) |
| Switching Throughput (Aggregate) | 7.2 Tb/s (non-blocking) |
| Latency (Port-to-Port) | 90 ns |
| Serial Console Port | 1 x RJ-45 |
| Management Ethernet Port | 1 x 10/100/1000Mb RJ-45 |
| USB Ports | 1 x USB |
| Power Supplies | Modular, Hot-Swappable (1+1 redundant) |
| Fans | Hot-Swappable (redundant) |
| Software | Onyx OS |
Specifications
- Product Line:
- SB7700 Series
- Type:
- Infiniband Switch
- model:
- Mellanox MSB7790-ES2F
- Switching Capacity:
- 7.2 Tbps
- Form Factor :
- 1U Rack Mountable
- Ports Quantity:
- 36
- Ports Interface:
- QSFP28
- Ports Speed:
- 100Gb
- Uplink Ports Quantity:
- -
- Network Management Type:
- Fully Managed
- Stackable:
- No
- Internal Ports Quantity:
- Not Applicable
- Layer:
- 2
- POE Standard:
- N/A
- Cooling:
- Front-to-Rear, Redundant Fans
- RAILS:
- NO
- PSU PN:
- MTEF-PSF-AC-A
- FAN PN:
- MTEF-FANF-A
- PSU Quantity:
- 2
- PSU Power:
- 460W
- Fan Quantity:
- 4
- License:
- -
