N9K-C93240YC-FX2 CISCO NEXUS 9K FIXED 48 PORT 25GB SFP28 12 PORT 100GB QSFP28 SWITCH
Brand:
CISCO
|
Part Number: N9K-C93240YC-FX2_22957
Description
N9K-C93240YC-FX2 CISCO NEXUS 9K FIXED 48 PORT 25GB SFP28 12 PORT 100GB QSFP28 SWITCH
Cisco Nexus 93240YC-FX2
| Device Type | Switch - 48 ports - L3 - managed |
| Manufacturer Part Number | N9K-C93240YC-FX2 |
| Product Collection | Cisco Nexus C9300-FX2 series |
| Ports | 48x 1/10/25Gb/s SFP, 12x 40/100 Gb/s QSFP |
| Supported speeds | 1/10/25 Gb/s on downlinks 40/100 Gb/s on uplinks |
| Bandwidth | 4.8 Tb/s |
| Active SPAN sessions | 4 |
| MAC Address Table Size | 256K entries |
| Routing Protocol | OSPF, RIP, RIP-2, BGP, EIGRP, HSRP, PIM-SM, MSDP, ECMP, MPLS |
| Compliant Standards | IEEE 802.1ae |
| Features | Layer 3 switching, Spanning Tree Protocol (STP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Virtual PortChannel (vPC) technology, MACsec support, 5 fans, Virtual Extensible LAN (VXLAN), Source-Specific Multicast (SSM), Ethernet Virtual Private Network (EVPN), 40MB system buffer, Power On Auto Provisioning (POAP) |
| CPU | 4 cores |
| Memory | 24 GB |
| SSD Drive | 128 GB |
| Power Supply | 1100 W |
| Capacity | Multiple Spanning Tree Protocol instances: 64 ¦ HSRP groups: 490 ¦ ACL entries (ingress): 5000 ¦ Maximum number of links in a port channel: 32 ¦ Maximum number of port channels: 512 ¦ ECMP paths: 64 ¦ Virtual Routing and Forwarding (VRF) instances: 16000 ¦ VLANs supported: 3967 ¦ ACL entries (egress): 2000 ¦ IGMP snooping groups: 32000 ¦ Multicast routes: 32000 ¦ NAT entries: 1023 |
| Included |
5X Cisco port side exhaust Fan module for N9K-C93240YC-FX2 2X Cisco 1100W port side exhaust Power Supply 80PLUS Platinum for N9K-C93240YC-FX2 |
| Chassis Form Factor | 1U |
| Enclosure Type | Rack-mountable |
| Chassis Dimensions | 2.1" x 17.3" x 23.3" |
| Airflow | Back to Front |
Specifications
- Product Line:
- Cisco Nexus
- model:
- N9K-C93240YC-FX2
- brand:
- CISCO
- Series:
- Nexus 9000
- SFP Ports:
- 48 x 25G
- QSFP Ports:
- 12 x 100G
