Cisco WS-C2960-48PST-L 48x RJ-45 100Mb 4x Combo RJ-45 / SFP 1Gb - PoE Switch
Brand:
CISCO
|
Part Number: WS-C2960-48PST-L
Description
Cisco WS-C2960-48PST-L 48x RJ-45 100Mb 4x Combo RJ-45 / SFP 1Gb - Power over Ethernet Switch
The WS-C2960-48PST-L is a fixed-configuration access layer switch utilizing the LAN Base feature set for comprehensive Layer 2 multiservice switching. Its architecture is built around 48 10/100 Fast Ethernet ports that provide standard IEEE 802.3af PoE (up to 15.4W per port) with a total power budget of 370W. The uplink architecture is ''flex-purpose'' providing two 10/100/1000BASE-T RJ-45 copper ports and two SFP-based Gigabit Ethernet ports for fiber connectivity. The device operates on a 16 Gbps switching fabric with a forwarding rate of 13.1 Mpps, optimized for wire-speed performance at the 100 Mbps edge. It supports up to 255 active VLANs and maintains an 8,000-entry MAC address table. Administratively, it supports advanced Layer 2 features including 802.1Q trunking, Dynamic Trunking Protocol (DTP), and Link Aggregation Control Protocol (LACP/802.3ad). Security is integrated through hardware-based MAC-level filtering, Bridge Protocol Data Unit (BPDU) Guard, and Port Security.
RELIABLE DELIVERY
Packaged Securely
Your product will arrive packaged carefully, according to internal standards of item protection. The item is handled professionally, you can be sure that your order will arrive in perfect condition.
ALWAYS ON TIME
With Our Own Logistics
Thanks to our own fleet of vehicles, we are able to ensure fast and reliable delivery of very large goods, such as complete server systems and data centers. We offer individual service and full control over the transport of your goods. Trust us to take care of your transport needs and deliver your products on time within Europe
SPECIFICATION
| Manufacturer | Cisco |
| Product Line | Catalyst 2960 Series |
| Model | WS-C2960-48PST-L |
| Ports | 48 x 100Mb RJ-45 |
| Uplink Ports | 4 x 1Gb Combo RJ-45 / SFP |
| Management | Fully Managed |
| Stackable | Yes |
| Internal Ports | Not Applicable |
| Form Factor | 1U Rack Mountable |
| Layer | 2 |
| POE Standard | PoE |
| POE Power | 370W |
| Switching Capacity | 16 Gbps |
| Mounting | YES |
| Cooling | Active (PN: Integrated) |
| Condition | A used item that has been kept in perfect conditions in a large data center. Looks like new, with no signs of use. Comes from a legitimate source. |
| Warranty | 1 Year |
DETAILED SPECIFICATION
| Feature / Characteristic | Specification |
|---|---|
| Ports | 48 x 10/100 Ethernet ports (IEEE 802.3af PoE) |
| Uplink Ports | 2 x 10/100/1000 RJ-45 and 2 x SFP (Gigabit) |
| Switching Capacity | 16 Gbps |
| Throughput (64-byte packets) | 13.1 million packets per second (13.1 Mpps) |
| Latency (100 Mbps) | < 20 µs (LIFO 64-byte packets) |
| MAC Address Table Size | 8,000 entries |
| Routing Table Size | N/A (Layer 2 Only Switch) |
| Maximum Power Rating | 470 W (with full 370W PoE load) |
| Idle Power Consumption | 45 W |
| Maximum Heat Dissipation | 341 BTU/hr |
| Form Factor | 1U rack-mountable |
| Dimensions (W x D x H) | 44.5 x 33.0 x 4.4 cm (17.5 x 13.0 x 1.73 in) |
| Weight | 5.44 kg (12.0 lb) |
| Operating Temperature | -5°C to 45°C (23°F to 113°F) |
| Storage Temperature | -25°C to 70°C (-13°F to 158°F) |
| Operating Relative Humidity | 10% to 95%, non-condensing |
| Storage Relative Humidity | 10% to 95%, non-condensing |
| Compliance | UL 60950-1, CAN/CSA 22.2, EN 60950-1, AS/NZS 60950-1, IEC 60950-1 |
Specifications
- Product Line:
- Catalyst 2960 Series
- Type:
- Power over Ethernet Switch
- model:
- Cisco WS-C2960-48PST-L
- brand:
- CISCO
- Series:
- 2960
- SFP Ports:
- 2 x 1G
- Switching Capacity:
- 16 Gbps
- RJ-45 Ports:
- 48 x 100M
- Form Factor :
- 1U Rack Mountable
- Ports Quantity:
- 48
- Ports Interface:
- RJ-45
- Ports Speed:
- 100Mb
- Uplink Ports Quantity:
- 4
- Uplink Ports Interface:
- Combo RJ-45 / SFP
- Uplink Ports Speed:
- 1Gb
- Network Management Type:
- Fully Managed
- Stackable:
- Yes
- Internal Ports Quantity:
- Not Applicable
- Layer:
- 2
- POE Standard:
- PoE
- POE Power:
- 370W
- Cooling:
- Active
- RAILS:
- YES
- PSU PN:
- Fixed
- FAN PN:
- Integrated
- PSU Quantity:
- 1
- PSU Power:
- -
- Fan Quantity:
- 1
- License:
- -
