| Manufacturer Part Number | 2400NX-HW |
| Manufacturer Part Option | NX 2400 |
| Brand | FireEye |
| Product Type | Network Security Appliance |
| User Count | 500 |
| OS Support | Microsoft Windows |
| Performance | Up to 50 Mbps |
| Network Monitoring Ports | 4x 10/100/1000 BASE- T Ports |
| Network Ports Mode of Operation | Inline Monitor, Fail-Open, Fail-Close, or Tap/Span, HW Bypass |
| Management Ports (rear panel) | 2x 10/100/1000 BASE- T Ports |
| IPMI Port (rear panel) | Included |
| Front LCD & Keypad | Included |
| PS/2 Keyboard and Mouse, DB15 VGA Ports (rear panel) | Included |
| USB Ports (rear panel) | 2x Type A USB Ports |
| Serial Port (rear panel) | 115,200 bps, No Parity, 8 Bits, 1 Stop Bit |
| Drive Capacity | Single 500 GB HDD, Internal, fixed |
| Enclosure | 1RU, Fits 19 inch Rack |
| Chassis Dimension WxDxH | 17.2" x 24.1" x 1.70" (437 x 612 x 43.2 mm) |
| DC Power Supply | Not Available |
| AC Power Supply | Non-redundant, non-FRU, internal 500 watt, 100 ~ 240 VAC 5 – 2.5A, 50-60 Hz IEC60320-C14 inlet |
| Power Consumption Maximum (watts) | 210 watts |
| Thermal Dissipation Maximum (BTU/h) | 717 BTU/h |
| MTBF (h) | 55,200 h |
| Appliance Alone / As Shipped Weight lb. (kg) | 24 lb. (11 kg) / 39 lb. (18 kg) |
| Regulatory Compliance Safety | IEC 60950 EN 60950 CSA 60950- 00 CE Marking |
| Regulatory Compliance EMC | FCC (Part 15 Class-A), CE (Class-A), CNS, AS/NZS, VCCI (Class A) |
| Security Certifications | CC NDPP v1.1 |
| Environmental Compliance | RoHS, REACH, WEEE |
| Operating Temperature | 10° C to 35° C Tested from 0°C to 40°C for additional margin |
| Non-Operating Temperature | -40°C to 70°C |
| Operating Relative Humidity | 8% - 90% (noncondensing) |
| Non-Operating Relative Humidity | 5% - 95% (noncondensing) |
| Operating Altitude | 5,000 ft |
| IPS Performance | 50 Mbps |
| Concurrent Connections | 15K |
| New Connections Per Second | 750/Sec |
| Packets Per Second | 4K/Sec |
