T5600-2LFF DELL PRECISION 1X INTEL XEON E5-2609 0 @ 2.40GHZ RAM 16GB(4X 4GB DDR3 4X 1067MHZ)
Brand:
DELL
|
Part Number: T5600-2LFF
Description
T5600-2LFF DELL PRECISION 1X INTEL XEON E5-2609 0 @ 2.40GHZ RAM 16GB(4X 4GB DDR3 4X 1067MHZ)
PN: T5600-2LFF
SPECS:
Technical data | Configurations supported |
Memory type | DDR3 1333 MHz and RDIMM 1600 MHz ECC |
Memory connectors | 4 DIMM slots with one processor; 8 DIMM slots with two processors |
Supported memory module capacity | 4 GB, 8 GB and 16 GB RDIMM ECC |
Minimum memory capacity | 4 GB |
Maximum memory capacity | One 64 GB processor; Two 128 GB processors |
Sound | |
Type | Model |
Integrated | Realtek ALC269 High Definition Audio |
Network | |
Type | Model |
Integrated | Intel 82759 |
Storage | |
Type | Technical data |
Externally accessible drive bays | Slimline SATA optical drive bays: one bay |
5.25-inch drive bays: one bay | |
Supports one 3.5-inch SATA device, one memory card reader, one 5.25-inch optical drive, or up to two 2.5-inch SAS / SATA / SSD hard drives (with optional adapters) | |
Drive bays accessible from inside | Two 3.5-inch hard drive bays - Supports two 3.5-inch SATA drives or two 2.5-inch SATA or SAS hard drives (with shells) |
External connectors | |
Connector type | Technical data |
Sound | Front panel: microphone input, headphone output |
Rear Panel: Line Out, Mic In / Line In | |
Movie | According to the graphics card: |
DVI connector | |
DisplayPort connector | |
DMS-59 | |
Network card | One RJ-45 connector |
USB | Front panel: three USB 2.0 connectors and one USB 3.0 connector |
Back Panel: Five USB 2.0 connectors and one USB 3.0 connector | |
Internal: Three USB 2.0 connectors | |
Serial | One 9-pin connector (rear), 16550C compliant |
PS / 2 | Two 6-pin mini-DIN connectors |
Connectors on the system board | |
Connector type | Technical data |
Serial ATA (Hard Drive) | Four 7-pin connectors |
Serial ATA (Optical Drive) | Two 7-pin connectors |
SFF-8087 mini-SAS | Two 36-pin connectors (via PERC card) |
Internal USB device | One 10-pin connector (supports two devices) |
CPU fan | Two 5-pin connectors |
Case fan | Three 3-pin connectors |
PCI 2.3 | One 124-pin connector |
PCI Express x16 | Two 164-pin connectors |
Front panel controls | One 28-pin connector |
USB connectors on the front panel | One 20-pin connector |
Audio HDA connector on the front panel | One 10-pin connector |
Processor | Two sockets with 2011-pin connectors |
memory | Eight 240-pin connectors |
12 V power supply | Two 8-pin connectors |
Power | One 24-pin connector |
Extension bus | |
Type | Speed |
PCI Express 3.0 slot | 3.0 x4 slot - 4 GB / s; two 3.0 x16 slots - 16 GB / s |
PCI Express 2.0 slot | 2.0 x4 slot - 2 GB / s |
PCI 2.3 | PCI 2.3 (32-bit, 33 MHz): 133 MB / s |
SATA 1.0 and 2.0 | 1.5 Gbps and 3.0 Gbps |
USB 2.0 and 3.0 | 1.2 Mb / s Low Speed, 12 Mb / s Full Speed, 480 Mb / s High Speed, 5 Gb / s Slow Speed |
Power | |
Variable | Technical data |
Coin-cell battery | CR2032 3V lithium coin cell |
Tension | 100-240 VAC, 50/60 Hz, 5.0 A |
Power | 635W / 825W (input voltage 100-240V AC) |
Maximum Heat Dissipation - Calculated from rated power in watts | 825 W: 3,086.60 BTU / hr 635 W: 2,484.00 BTU / hr |
