- Out-of-Stock
General Information | |
Manufacturer Part Number | BL460C G8-2SFF |
Manufacturer Part Option | 641016-B21 |
Inside | 1X HP MAINBOARD FOR BLADE WS460C GEN8 E5-V |
Brand | HP |
Product Type | BLADE |
Technical Information | |
Chipset |
Intel® C600 Series Chipset Intel® E5-2600 and 2600v2 Processor Families |
On System Management Chipset | HP iLO (Firmware: HP iLO 4) |
Memory Protection |
Advanced ECC Memory Online Spare Mode (Rank Spare Mode) Lockstep Mode |
Memory Type |
HP SmartMemory DDR3 Load Reduced (LRDIMM) Registered (RDIMM) Unbuffered ECC (UDIMM) |
Maximum (LRDIMM) | 512GB (16 x 32GB) up to 1333MHz at 1.35V |
Maximum (RDIMM) |
256GB (16 x 16GB) up to 1866MHz at 1.5V 384GB (16 x 24GB) up to 1333MHz at 1.35V |
Maximum (UDIMM) | 128GB (16 x 8GB) up to 1600MHz at 1.5V |
Interfaces |
USB 2.0 Port One (1) internal USB 2.0 connector for USB flash media drive keys NOTE: The above options are for integrated hypervisor virtualization environments needing a low cost boot solution with the highest performance and reliability. NOTE: The internal USB 2.0 Port is not available when the HP 24GB (1x24GB) Three Rank x4 PC3L-10600R |
Dimensions (H W D) | 18,07 x 5,54 x 51,76 cm |
